的主要用途与介绍/Brief Introduction：

该线由切线式挤出机螺杆洗瓶烘箱一体化机、口服药液分装轧盖机二台单机手机游戏版构成，划分为进行维护清洁、干燥处理无菌和分装粘口二个工作上区，全程可一体化制作，也可单机手机游戏版应用。可搞定淋水、超音波波进行维护清洁、冲水、冲气、烘箱无菌、待冷却、分装、理盖、戴盖、轧盖等程序。The line is made up of two single machine, one straight-line screw bottle washing and drying machine and one oral liquid filling and capping machine. The line is divided into cleaning, drying, sterilization and filling sealing three workspace, all can joint production, also can use single. It can complete water spray, ultrasonic cleaning, water flushing, air flushing, drying sterilization, cooling, filling, cap arranging, capping, sealing, etc.

特殊性/Characteristic：

主要采用超声心动图波清洁及水蒸气轮流冲洗器、远红外高温度杀菌、双头装灌与封好等技术工艺。整线互通重新操作流程。操作流程轻松便，达到了机电专业合二为一化。Using ultrasonic cleaning and water washing alternately, far-infrared high-temperature sterilization, such as long filling and sealing technology. The automatic control of the whole line linkage. Simple and convenient operation, electromechanical integration is realized.

工艺性能参数/ Technical Parameters：

生产能力technical parameters	80-150瓶/分80-150 bottles/min
适用性规模 Cutting dimension	5-20ml
电  容  量Amount of electric capacity	65Kw(进来普通工作任务36Kw)(includ💃ing normal working 36 kw)
POS机毛重machine net weight	6800Kg
外形尺寸boundary dimension	9650×2360×1900mm（长×宽×高）(length x width x height)
