作用与百科/Brief Introduction：

滤油机是加入服用液钢化玻璃纸容器的新物料，彻底消除解決了往日服用液钢化玻璃纸容器的不好治疗效果。类似灌封机用到的PVC瓶，这样不仅不所需洗瓶机、烘干设备机，更不所需杀菌，会简单灌封。此机全主动理瓶、进瓶、包装，包装量相对安全稳定，无漏滴，无瓶不包装。上盖、密封率多达100%。此机方法先进典型，体积大小小、作业相对安全稳定、燥声低，进行维修部、难以清理省事等特征，齐全遵循GMP标准化。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本款型有减速和速度二者收获量供您首选。Note: this model has two kinds of low speed and high-speed production for your choice.

优点和缺点 Characteristic

◆远程服务器选主要用于各种各样易折瓶口服药液计量检验灌装线和封好。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆很多设备组件均分为高端品牌高端品牌。All electrical components adopt famous brand◆该设备操作步骤形象简单方便，无瓶不分装，计量检测*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折塑料制品瓶灌封机的常见形式与方式Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型口服方式液易折塑料制品瓶灌封机其主要理瓶器、理盖器、主转向系统的系统的、云同步带气隙送罐配置、空罐检漏配置、包装公司、去除配置、热熔连接封公司、气动弹簧机械设备制造手指尖夹瓶公司、伺服线束主轴电机气隙上瓶公司与出瓶公司等包含。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆机气在使用的补血口服液液易折泡沫塑料饮料瓶、盖有的是定超净区制作的，应该由泡脚药材同意证，于是瓶身与底盖经传播和"去承包"后可会进去灌封间。顺利通过理盖器、理瓶器的自行专向收集整理，剔出反相底盖及瓶身底口朝下的瓶，使专向后的包材喂料有规定地进去输料轮轨中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆定向生后内服液易折塑料材质瓶在运输在轨道总排名Directional oral liquid after folding plastic bottles in conveying rail out easily

系统叁数technical parameters：

型号model	NLGFY-40	NLGFY-80
装量区间The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
粘口率Hot sealing intensity	》99%
装量精度The load error	《1.5%
磨损率damage rate	《1.0%
电率power	2KW	3KW
主机电源Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
毛重 Weight	700Kg	800Kg
