的主要用途与概况/Brief Introduction：

全电脑定时液压泵式膏体酱灌装生产线生产线机.我企业习惯市厂业务需求开发设计的新厂品。设备用于SUS304不锈钢装饰管液压泵式记量泵执行工作灌装生产线生产线，且集电脑定时上盖、电脑定时旋盖、不间断不间断为一体式，经济性有用，拆迁赔偿体积小，比较主要用途于制药厂、肉食品、农药杀菌剂、蓝翔塑业有限公司所生产的、化妆师品等该行业的全自动包装机，复合GMP原则让。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

特别/characteristic：

◆采取轴向柱塞泵式测量泵执行力装灌，使用所有黏黏度液状体，定位精度不高；泵的架构采取快接式取下组织机构，更方便刷洗、消毒液。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆注塞泵式压力容器检验泵发动机活塞环金属的质地有所不同制造行业及溶剂物质的有所不同主要运用硅再生胶，四氟氯乙烯或其他金属的质地，特种情况主要运用瓷器金属的质地。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC有效控制设计，定频变频调速，半全自动化数量高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不灌装线，自动化计数器技能。Lack of bottle filling, automatic counting function◆装量调节利于，可以次调节全都收费检验泵的充填量，也可根据各类收费检验泵做微幅调节；的操作简变，调节飞速。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆罐装针头拥有防滴漏问题仪器，充填时前往瓶底罐装，慢提升，以防有气泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆服务器可适用人群有差异 规格参数的空瓶，优化用简，可在多日间内成功。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆整套装置按GMP请求的设计。The machine designed according to the requirements of GMP

技木指标/technic parameter：

不适用瓶盖产品规格Size of bottles	20-1000ml（选择规定订作）20-1000 - ml (according to your need）
选用矿泉水瓶孔径Apply the bottle diameter	¢20-¢150mm
适用人群盖子规格为Apply the lid specifications	¢20-¢70mm
种植本事 production capacity	四头包装：1000-2500瓶/分钟 Four filling head: 1000-2500 bottles per hour 八头灌装设备：2500-4000瓶/H Eight head filling: 2500-4000 bottles per hour 12头装灌：4000-6000瓶/个小时 12 head filling: 4000-6000 bottles per hour
装量粗差The load error	±1%
旋盖通过率Screw cover percent of pass	≥99%
电源开关power supply	380V，50HZ
公率power	3.0KW
供气gas sources	0.4-0.75MPA
极限速度管理speed control	交流变频变频调速variable speed
